Laboratory Equipment Factory Supplier Lab Beating Homogenizer

Product Name: Homogenizer
Brand: BKMAMLAB

Product Usage: A widely used device in multiple fields. Its main function is to homogenize, mix, or disperse samples or substances through high-speed vibration and mechanical action.

Precautions:

It is not recommended to adjust the paddle plate too far forward; it is sufficient for the paddle plate to press against the homogenization bag.

The power plug must be fully inserted. Loose connections may affect the computer controller and cause a system crash. If a crash occurs, turn off the rear power switch, wait 3 minutes, then restart the device.

Do not open the homogenizer door arbitrarily when the paddle plate is working, to prevent sample liquid from spilling. Press the "Start/Stop" button to stop the device automatically. After closing the door, press "Start/Stop" again to resume operation.

Product Parameter Table

Product	Standard Type	UV Sterilization Type	Heating Sterilization Type
Model	BPD-10A	BPD-20A	BPD-30A
Display Mode	4.3 4.3-inch touch screen	4.3 4.3-inch touch screen	4.3 4.3-inch touch screen
Control Mode	Microcomputer control + 8-stage programming	Microcomputer control + 8-stage programming	Microcomputer control + 8-stage programming
Pat Speed	3-12 seconds/time (supports 8 groups of timed settings)	3-12 seconds/time (supports 8 groups of timed settings)	3-12 seconds/time (supports 8 groups of timed settings)
Pat Time	0.1-99 minutes 59 seconds or continuous operation	0.1-99 minutes 59 seconds or continuous operation	0.1-99 minutes 59 seconds or continuous operation
Pat Spacing	0-50mm adjustable	0-50mm adjustable	0-50mm adjustable
Sterilization Function	/	,Yes, sterilization wavelength 253.7nm	Yes, sterilization wavelength 253.7nm
Temperature Control Range	/	/	- 60ºC Room temperature-60°C
Voice Prompt	Yes	Yes	Yes
Effective Volume	3-400mL	3-400mL	3-400mL
Pat Plate Material	+ Stainless steel + special black compression sleeve	+ Stainless steel + special black compression sleeve	Stainless steel + special black compression sleeve
Sterile Bag Size	1730cm (Also compatible with BKMAMLAB® 2022cm, 2032cm homogenization bags)	1730cm (Also compatible with BKMAMLAB® 2022cm, 2032cm homogenization bags)	1730cm (Also compatible with BKMAMLAB® 2022cm, 2032cm homogenization bags)
Start Mode	Soft start (progressive speed increase from low to high)	Soft start (progressive speed increase from low to high)	Soft start (progressive speed increase from low to high)
Anti-Pinch Function	With automatic stop anti-pinch function	With automatic stop anti-pinch function	With automatic stop anti-pinch function
Others	Detachable window + tempered glass safety door	Detachable window + tempered glass safety door	Detachable window + tempered glass safety door
Pause Function	Yes	Yes	Yes
Power Supply/Power	220V 300W	220V 350W	220V 500W
Instrument Dimensions (DWH)	420230330mm	420230330mm

Homogenizer-1

Homogenizer-2

Homogenizer-4
